Pepperl Fuchs Diffuse mode sensor ML100-8-1000-RT/103/115

Pepperl Fuchs Diffuse mode sensor ML100-8-1000-RT/103/115

Output
Switching type The switching type of the sensor is adjustable. The default setting
is: light on
Signal output 1 NPN output, short-circuit protected, reverse polarity protected,
open collector
Switching voltage max. 30 V DC
Switching current max. 100 mA , resistive load
Voltage drop Ud ≤ 1.5 V DC
Switching frequency f 1000 Hz
Pepperl fuchs Diffuse mode sensor ML100-8-1000-RT/103/115

Response time 0.5 ms
Ambient conditions
Ambient temperature -30 ... 60 °C (-22 ... 140 °F)
Storage temperature -40 ... 70 °C (-40 ... 158 °F)
Mechanical specifications
Degree of protection IP67
Connection 2 m fixed cable
Pepperl Fuchs Diffuse mode sensor ML100-8-1000-RT/103/115

Material
Housing PC (Polycarbonate)
Optical face PMMA
Mass approx. 50 g
Cable length 2 m
Compliance with standards and directives
Directive conformity
EMC Directive 2004/108/EC EN 60947-5-2
Standard conformity
Standards UL 60947-5-2

Pepperl Fuchs Diffuse mode sensor ML100-8-1000-RT/103/115
